XM4200-5H/VC/G

ASL XM4200-5H/VC/G - analog short-arc lamp.

Warranty/Life

Technical specification

Power (W) - 4200
Rated Current (A.D.C.) - 140
Voltage (V.D.C.) - 30
Current Control Range (A.D.C.) - 80-150
Average Lumen Output (Lm) - 166000
Burning Position - H±20° V±20°
Forced Air Cooling (m/sec.) - 10-13
Anode (+) Base Ø - Pin Ø or Thread (mm) - 27-13
Cathode (-) Base Ø - Pin Ø or Thread (mm) - 27-13

Specs subject to change without notice. All trademarks, service marks, trade names and product names appearing on this page are the property of their respective owners.
