XM2000H/VC/G

ASL XM2000H/VC/G - analog short-arc lamp.

Replacement for LTI LTIX-2000W-H, OSRAM XBO 2000W/H OFR, Christie CXL-2000/20R, USHIO UXL-2000HR, Yumex YXL-20R, Superior Quartz SX20002

Warranty/Life

Warranty: 2700h

Technical specification

Power (W) - 2000
Rated Current (A.D.C.) - 70
Voltage (V.D.C.) - 28
Current Control Range (A.D.C.) - 50-85
Average Lumen Output (Lm) - 80000
Burning Position - H±20° V±20°
Forced Air Cooling (m/sec.) - 7-10
Anode (+) Base Ø - Pin Ø or Thread (mm) - 27-10
Cathode (-) Base Ø - Pin Ø or Thread (mm) - 27-12

Cross Reference

LTI - LTIX-2000W-H
OSRAM - XBO 2000W/H OFR
Christie - CXL-2000/20R
USHIO - UXL-2000HR
Yumex - YXL-20R
Superior Quartz - SX20002

XM2000H/VC/G replacement for LTIX-2000W-H, XBO 2000W/H OFR, CXL-2000/20R, UXL-2000HR, YXL-20R, SX20002

Specs subject to change without notice. All trademarks, service marks, trade names and product names appearing on this page are the property of their respective owners.
