XD6500HP/G

ASL XD6500HP/G is a digital short-arc lamp suitable for use in the following projectors: BARCO DP2K-32B, BARCO DP4K-32B, BARCO DP-100, BARCO DP-3000, CINEMECCANICA CMC D2, CINEMECCANICA CMC3 D2, CINEMECCANICA CMC4, CINEMECCANICA DPC-80, KINOTON DCP 30, KINOTON DCP 30 LX II - 4K, KINOTON DCP 30 MX II, KINOTON DCP 30 MX II-2/4K.

Replacement for LTI XDC-6500TA, OSRAM XBO 6500W/DHP OFR & XBO 6500W/HSLA OFR

Warranty/Life

Warranty: 600h

Technical specification

Power (W) - 6500
Rated Current (A.D.C.) - 170
Voltage (V.D.C.) - 39
Current Control Range (A.D.C.) - 120-175
Average Lumen Output (Lm) - 320000
Burning Position - H±15° V±15°
Forced Air Cooling (m/sec.) - 10-13

Cross Reference

LTI - XDC-6500TA
OSRAM - XBO 6500W/DHP OFR & XBO 6500W/HSLA OFR

Projector Reference

BARCO DP2K-32B
BARCO DP4K-32B
BARCO DP-100
BARCO DP-3000
CINEMECCANICA CMC D2
CINEMECCANICA CMC3 D2
CINEMECCANICA CMC4
CINEMECCANICA DPC-80
KINOTON DCP 30
KINOTON DCP 30 LX II - 4K
KINOTON DCP 30 MX II
KINOTON DCP 30 MX II-2/4K

XD6500HP/G replacement for XDC-6500TA, XBO 6500W/DHP OFR & XBO 6500W/HSLA OFR
