XD6001HTP/G
ASL XD6001HTP/G is a digital short-arc lamp suitable for use in the following projectors: CHRISTIE CP2000, CHRISTIE CP2000-H, CHRISTIE CP2000-S, CHRISTIE CP2000-SB, CHRISTIE CP2000-XB, CHRISTIE CP2000-ZX, CHRISTIE CP2230, CHRISTIE CP4230, CHRISTIE D4K35, CHRISTIE Roadie 25K, CHRISTIE Roadie 4K35, CHRISTIE Roadie 4K45, CHRISTIE Roadie HD+35K.
Replacement for LTI LTIX-6000W-DC & XDC-6000C, OSRAM XBO 6000W/DTP OFR, Christie CDXL-60, Superior Quartz SXD6000HTP
Warranty/Life
Warranty: 700hTechnical specification
Power (W) - 6000Rated Current (A.D.C.) - 155
Voltage (V.D.C.) - 39
Current Control Range (A.D.C.) - 120-170
Average Lumen Output (Lm) - 285000
Burning Position - H±15° V±15°
Forced Air Cooling (m/sec.) - 10-13
Cross Reference
LTI - LTIX-6000W-DC & XDC-6000COSRAM - XBO 6000W/DTP OFR
Christie - CDXL-60
Superior Quartz - SXD6000HTP
Projector Reference
CHRISTIE CP2000CHRISTIE CP2000-H
CHRISTIE CP2000-S
CHRISTIE CP2000-SB
CHRISTIE CP2000-XB
CHRISTIE CP2000-ZX
CHRISTIE CP2230
CHRISTIE CP4230
CHRISTIE D4K35
CHRISTIE Roadie 25K
CHRISTIE Roadie 4K35
CHRISTIE Roadie 4K45
CHRISTIE Roadie HD+35K
