XD4000SN/G

ASL XD4000SN/G is a digital short-arc lamp suitable for use in the following projectors: NEC NC1600C, NEC NC2000C, NEC NC2500S, NEC NC3200S, NEC NC3240S 4kW*.

Replacement for LTI XDC-4000N, OSRAM XBO 4000W/HPN, USHIO DXL-40SN

Warranty/Life

Warranty: 700h

Technical specification

Power (W) - 4000
Rated Current (A.D.C.) - 125
Voltage (V.D.C.) - 32
Current Control Range (A.D.C.) - 100-130
Average Lumen Output (Lm) - 190000
Burning Position - H±15° V±15°
Forced Air Cooling (m/sec.) - 10-13
Anode (+) Base Ø - Pin Ø or Thread (mm) - 30-14
Cathode (-) Base Ø - Pin Ø or Thread (mm) - 30-20

Cross Reference

LTI - XDC-4000N
OSRAM - XBO 4000W/HPN
USHIO - DXL-40SN

Projector Reference

NEC NC1600C
NEC NC2000C
NEC NC2500S*
NEC NC3200S*
NEC NC3240S 4kW*

* adapter required

XD4000SN/G replacement for XDC-4000N, XBO 4000W/HPN, DXL-40SN
