XD2000HTP/G

ASL XD2000HTP/G is a digital short-arc lamp suitable for use in the following projectors: CHRISTIE CP2000, CHRISTIE CP2000-H, CHRISTIE CP2000-S, CHRISTIE CP2000-SB, CHRISTIE CP2000-XB, CHRISTIE CP2000-ZX, CHRISTIE CP2220, CHRISTIE CP2230, CHRISTIE CP4220, CHRISTIE CP4230, CHRISTIE D4K25, CHRISTIE D4K35, CHRISTIE Roadie 25K, CHRISTIE Roadie 4K35, CHRISTIE Roadie 4K45, CHRISTIE Roadie HD+35K.

Replacement for LTI LTIX-2000W-DC & XDC-2000C, OSRAM XBO 2000W/DTP OFR, Christie CDXL-20, Superior Quartz SXD2000HTP

Warranty/Life

Warranty: 2400h

Technical specification

Power (W) - 2000
Rated Current (A.D.C.) - 80
Voltage (V.D.C.) - 25
Current Control Range (A.D.C.) - 50-85
Average Lumen Output (Lm) - 80000
Burning Position - H±15° V±15°
Forced Air Cooling (m/sec.) - 7-10

Cross Reference

LTI - LTIX-2000W-DC & XDC-2000C
OSRAM - XBO 2000W/DTP OFR
Christie - CDXL-20
Superior Quartz - SXD2000HTP

Projector Reference

CHRISTIE CP2000
CHRISTIE CP2000-H
CHRISTIE CP2000-S
CHRISTIE CP2000-SB
CHRISTIE CP2000-XB
CHRISTIE CP2000-ZX
CHRISTIE CP2220
CHRISTIE CP2230
CHRISTIE CP4220
CHRISTIE CP4230
CHRISTIE D4K25
CHRISTIE D4K35
CHRISTIE Roadie 25K
CHRISTIE Roadie 4K35
CHRISTIE Roadie 4K45
CHRISTIE Roadie HD+35K

XD2000HTP/G replacement for LTIX-2000W-DC & XDC-2000C, XBO 2000W/DTP OFR, CDXL-20, SXD2000HTP
