XD2000BA/G

ASL XD2000BA/G - digital short-arc lamp.

Replacement for USHIO PXL-20BA

Warranty/Life

Warranty: 2000h

Technical specification

Power (W) - 2000
Rated Current (A.D.C.) - 65
Voltage (V.D.C.) - 30
Current Control Range (A.D.C.) - 45-70
Average Lumen Output (Lm) - 80000
Burning Position - H±15° V±15°
Forced Air Cooling (m/sec.) - 7-10

Cross Reference

USHIO - PXL-20BA

Specs subject to change without notice. All trademarks, service marks, trade names and product names appearing on this page are the property of their respective owners.
